These physical attributes provide users with some of the best image quality AGM has produced to date with potential detection ranges up to 2600 yards. The Rattler-C V2 thermal clip-ons have a high-sensitivity sensor, which provides a clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. The Rattler-C V2 clip-on The Rattler TC can easily be attached in front of day scopes to quickly convert a day optic into a thermal imaging device without any special tools or equipment required. Powered replaceable and rechargeable Li-ion battery the AGM Rattler-C V2 provides up to 11 hours of continuous battery life on a single charge (2 batteries included). An external 5V power bank (battery pack) can be easily connected via a USB-C connector for a significant increase of operating time. Onboard Wi-Fi module is also available for live video streaming and video/images recording via mobile application.
FEATURES:
- Quick conversion of daytime optics into thermal imaging scope
- 12μm high-sensitivity thermal detector, NETD < 20mK
- Fast 50Hz imaging
- High resolution OLED display
- Adjustable color palettes
- On-board video/audio recording and image capture
- Built-in EMMC storage (16 GB)
- Shot Activated Recording (SAR)
- Wi-Fi data transmission
- Stadiametric rangefinder
- Standby mode
- 9 - 11 hours battery life (depending on model)
- External power supply compatibility
- Detector type: 12μm VOx Uncooled Focal Plane Array
- Refresh rate: 50 Hz
- Resolution: 256 x 192
- FOV: 9.3° × 6.9°
- Waterproof & shockproof
- 5-year warranty
SPECIFICATIONS:
- Shot-Activated Recording -Yes
- Max. Recoil - 1000 g/0.4 ms
- Dimensions - 184 × 68 × 67 mm (7.2 × 2.7 × 2.6 in)
- Flat Field Correction (FFC) -Auto, Manual, External Correction
- Palettes - Black hot, White hot, Red hot, Fusion
- Exit Pupil Diameter - 22 mm
- Distance Measurement - Yes (Stadiametric
- Scene Mode - Cold, Warm
- Video Recording - Yes
- Defective Pixels Correction (DPC) - Yes
- Audio Recording - Yes
- Detector type - 12μm VOx Uncooled Focal Plane Array
- Standby Mode - Yes
- Refresh rate - 50 Hz
- Resolution - 256 × 192
- Detection Range (6' object) - 1000 m/yd
- Snapshot -Yes
- Lens system - 19 mm; F/1.0
- NETD - Less than 35 mK (25°C, F# = 1.0)
- Optical magnification - 1×
- Field of view (H × X) - 9.3° × 6.9°
- Hot Track - Yes
- Eye relief - 10 mm
- Display - 0.39-inch, OLED, 1024×768
- Storage - Built-in EMMC (16 GB)
- Battery Type - 4400mAh Replaceable and Rechargeable Li-ion Battery
- Wi-Fi - Yes
- Battery Life (Operating) - 11.5 h (25°C, with hotspot off)
- External power supply - 5 VDC, 2 A, USB Type-C
- Operating Temperature Range - -30°C to +55°C (-22°F to 131°F)
- Weight - 0.5 kg (1.10 lb)
- Protection Level - IP67
- Package Includes - Thermal Imaging Clip-On, Mount, Two Rechargeable Battery, Charger, USB Cable, Lens Cloth, Manual, Carrying Case
- Focus Range - 0.5 m to infinity
